Chip Inductors – 1008LS (2520)
- Lower DCR than other 1008 inductors
- Ferrite construction for high current handling
- Inductance values: 1.0 – 100 µH
Our 1008LS Series wirewound chip inductors have a ferrite-ceramic core construction that gives higher current handling and lower DCR in an 1008 (2520) chip size. Inductance values range from 1 uH to 100 uH, with a ±5% for all values in the series.
- Inductance values from 1.0 µH to 100 µH (5% tolerance)
- Higher Q and lower DCR than our 1008CS/HS Series
- Ferrite construction for higher current carrying capacity
- Defense Supply Center CID A-A-59698
- AEC-Q200 Grade 3 (−40°C to +85°C)
